Módulo Duplex LC MM compatible Cisco 1000BASE-SX GE SFP 850nm 550m
Articulos al por mayor en Madrid
Caracteristicas:
| Nombre: | Módulo Duplex LC MM compatible Cisco 1000BASE-SX GE SFP 850nm 550m | |||
|---|---|---|---|---|
| Referencia: | GLCSXMMD | F. Tecnica: | NO DISPONIBLE | |
| Certificado: | NO DISPONIBLE | |||
| Color: | OTROS | Medida: | 500 m | |
Descripcion:
1 Features
1.1 850nm VCSEL laser and PIN photodetector
1.2 Meet SFP MSA and SFF-8472 with LC receptacle
1.3 Digital diagnostic monitoring
1.4 500m transmission with 50/125µm MMF,300m transmission with 62.5/125µm MMF
1.5 Hot-pluggable
1.6 Metal enclosure for lower EMI
1.7 +3.3V Single power supply
1.8 Qualified to meet the intent of Bellcore reliability practices
1.9 LVPECL logic interface simplifies interface to external circuitry
1.10 LVTTL logic level RX LOS
1.11 With pull de-latch
1.12 Operate data rate:1.25Gb/s;
1.13 operate temperature Standard :0 to +70°C,Extended : -20 to +85°C,industrial : -40 to +85°C
1.14 Complies with RoHS directive
2 Application
2.1 ATM
2.2 SONET
2.3 Fiber Channel
2.4 Gigabit Ethernet
2.5 Switches
2.6 Routers
2.7 Hubs
3 General
The optical transceiver is compliant with the Small Form-Factor Pluggable (SFP) Multi-Source Agreement (MSA) and SFF-8472. It offers previously unavailable system cost, upgrade, and reliability benefits by virtue of being hot-pluggable. The optical transceiver is ROHS compliant, each of the components is lead-free.
